JK
JK BMS 200A (8-20S) w/ Bluetooth
JK BMS 200A (8-20S) w/ Bluetooth
8 in stock
Couldn't load pickup availability
JK BMS B2A20S20P 8-20S 200A with Bluetooth
Enhance your battery management system with the JK BMS B2A20S20P, designed for 8 to 20-series lithium-ion cells. This 200A BMS features Bluetooth connectivity, enabling real-time monitoring and management via your smartphone. It ensures optimal battery protection with built-in safeguards against overcharge, over-discharge, and short circuits.
Key Features:
- Current Rating: Supports up to 200A.
- Bluetooth Functionality: Monitor and manage settings remotely.
- Versatile Compatibility: Ideal for various lithium battery applications.
| B2A20S20P | |
|---|---|
| Cells in series(LiFePO4) | 8S-20S |
| Cells in series(Li-ion) | 7S-20S |
| Cells in series(LTO) | 12S-20S |
| Cont. discharge | 200 A |
| Cont. charge | 200 A |
| Max. discharge (2min) | 350 A |
| Balance current | Active 2 A (Adjustable) |
| Internal Resistance | 0.47 mΩ |
| Overcharge current protection | 10 - 200 A (Adjustable) |
| Overcharge/over-discharge voltage protection | 1.2 - 4.35 V (Adjustable) |
| Temperature protection | Yes |
| Short Circuit protection | Yes |
| Coulomb counter | Yes |
| Communication | Bluetooth/RS485/CANBUS |
| Size | 162x102x20 mm |
Box Contents:
- Bluetooth Enabled BMS
- Balancing Wires
- Temperature Probes
- Fair-use warranty*
I recently bought and received the 200A JKBMS, and I am extremely pleased with the overall experience. From the purchasing process to the speed and efficiency of the delivery, everything exceeded my expectations.
First and foremost, the website "cellsupplysa" where I purchased the 200A JKBMS was user-friendly and provided all the necessary information. The product description was detailed, allowing me to understand all the features and functionalities of this particular model. Additionally, the website's secure payment gateway gave me confidence and peace of mind during the transaction process.
In conclusion, purchasing and receiving the 200A JKBMS has been an absolute delight. The seamless process, from ordering to delivery, coupled with the top-notch customer service, has left me extremely satisfied. The JKBMS itself has exceeded my expectations in terms of quality, performance, and ease of use. I highly recommend the 200A JKBMS to anyone in need of an efficient and reliable battery management system.
I ordered the item in the evening 30/01/2024
It was delivered 31/01/2024 Quick fast efficient service from seller Highly recommended The JK BMS perfect as always Trust them My 3rd one Installed, configured nvnvand working I need the 200 A for my 10kw Must inverter Since the BMS can handle high current draw and a max 0f 350A Work like a charm Thanks for excellent service and product
